Waterjet Loom SD-851
Price on Request
Product Specifications
- SdB51 series water jet loom is developed based on traditional model, while we lmproved its weak point, now it is able to weave ultra-fine and high density fabrics at high speed.
Products Description
| Item | Description | Brand | |
|---|---|---|---|
| Reed width | Nominal (cm) | 150,170, 190, 210, 230, 280, 320, 360 | |
| Weft Selection | 1 color, 2 color,3 color, 4 color | ||
| Structure | Robust structure, Strengthen body with high CNC precision. | ||
| Driving | Starting method | Quick start | |
| Gear box | Shanghai Yinchun | ||
| Motor capacity | 1.8KW, 2.2KW, 2.8KW, 3.3KW, 3.7KW | ||
| Oil seal | TTO, Taiwan | ||
| Belts | EC-Bird | ||
| Main Bearings | Nachi, Japan | ||
| Bearing bush | Dubang, America | ||
| All type of bolts and screws | Shanghai Yinchun | ||
| Brake pad | Shanghai Yinchun | ||
| Operation | Stopped by the electromagnetic brake at the programmed position. (Arrange, run, stop, forward inching, reverse inching, programmed position stop after one turn reverse rotation optional) | ||
| Beating shaft | 10mm thickness steel shaft Crank beating, oil bath lubricating system. | ||
| Beating | The reed | Standard SS #304 high quality reed | |
| Pump System | Jilong (JL) | ||
| Weft Insertion | Nozzle | MDH, Korea | |
| Plunger | MDH, Korea | ||
| One way valve | TAE BAEK, Korea | ||
| Shedding | Feeder | Shanghai Yinchun | |
| Plain | EC-Bird by Shanghai Yinchun | ||
| Cam | EC-Bird by Shanghai Yinchun | ||
| Shedding | Dobby | Top mounted mechanical or electronic dobby With 16 heald frames | EC-Bird by Shanghai Yinchun |
| Heald frame | Heavy duty aluminum frame | Shanghai Yinchun | |
| Heald wire | Nylon heald wire | Shanghai Yinchun | |
| Let-off | Mechanical | Standard mechanical let-off system | |
| Electronic | With Servo motor, synchronized with electronic controller | Shanghai Yinchun | |
| Take-up | Transmission | Zero max transmission | Shanghai Yinchun |
| Flange diameter | 800mm or 1000mm (optional) | ||
| Back rest roller | Twin type, 102mm roller with special anti rusting treatment with 9mm let-off spring | ||
| Mechanical | Standard mechanical take-up system | ||
| Electronic | Electronic take-up synchronized with electronic controller | Shanghai Yinchun | |
| Cloth passage | Standard, Tsudakoma type | ||
| Cloth roller | Standard aluminum cloth roller | Shanghai Yinchun | |
| Weft supply stand | Floor mounted stand | ||
| Selvage formation | Twisted by planetary gear system | ||
| Waste weft removal | Catch cord with spindle twisting system | ||
| Cutter | Mechanical cutter | EC-Bird | |
| Temple | Top mounted: 2 barrel type with 2 rings type. | Jilong (JL) | |
| Water suction | Slit tube suction system. | ||
| Stop motion | Weft yarn | Feeler | |
| Stop indication | 4 color multi function indication lamps. | ||
| Painting | Well equipped production line to remove dust, rust particles and inorganic debris by sand blasting method. (1) Zing epoxy paint 2 times, (2) Middle epoxy paint 2-3 times, (3) Surface paint 2 times. | ||
| Electronic control system | All in one electronic controller with digital display | Shanghai Yinchun | |
| Weave navigation system | Wi-Fi connect, smart Cloud based loom monitoring system. For operational data, storage and navigation. | Shanghai Yinchun | |
