MODEL SU788 RAPIER LOOMS
Price on Request
Product Specifications
- This machine is specially designed with heavy and thick wall body structure and with all high-tech functions.
- This machine is suitable to manufacture natural fiber, artificial fiber, and decorative yarns with narrow heavy fabrics.
Products Description
| Specifications | Details |
|---|---|
| Reed Width | 190 – 280(cm) |
| Speed | 170 – 220(rpm) |
| Power | 2.2(KW) |
| Shedding | Mechanical Dobby, 20 Shaft |
| Structure | Case Structure with Oil Lubrication |
| Feeder | Electronic Feeder (6 Small) |
| Color | 6 Color, Mechanical Color Selector |
| Head Frame | 16 Head Frame |
| Roll Up | Positive continuous mechanical take-up |
| Run – In – Wrap | Positive continuous mechanical let-off |
| Warp Stop Motion | Six rows Electronic Device, Auto Stop Motion |
| Beam/Clothroll | 600mm beam 1.5 pcs. / 1.5 sets cloth roll |
| Control | Advance Microcomputer LCD Control Panel |
| Reed | 1.5 pcs |
| Dropper/Wire | 6000 Dropper / 6000 Nylon Wire |
| Net Weight | 2200KG |
- One Body and Honeycomb Structure
- High Strength and Vibration Absorption
- Ensures Stability and Reliability of Jacquard Body
- One Body and Honeycomb Structure
- High Strength and Vibration Absorption
- Ensures Stability and Reliability of Jacquard Body
